Frangible Tank Roof Design

See figures 7 and 8.

Frangible tank roof design.

The reasoning behind present api design formulas is reviewed. A frangible roof joint forming a flexible gastight connection between a tank shell and a roof comprising an annular link mechanism sealingly secured at or adjacent a first edge thereof to a rim of. In such tanks the roof to shell joint is intended to fail in the event of overpressurization venting the tank and containing any remaining fluid. That is of course if the tanks are built according to the rules for frangible roofs.

This paper presents the results of an investigation into the frangible joint behavior of tanks designed to api 650 rules. Failure of the roof to shell junction can be expected to occur when the stress in the compression ring area reaches the yield point says f 6 calculated failure pressure. The api 650. A frangible roof joint forming a flexible gastight connection between a tank shell and a roof comprising an annular link mechanism sealingly secured at or adjacent a first edge thereof to a rim of the tank and sealingly secured at or adjacent a second edge thereof to the periphery of the roof.

The concept of frangible roof only applies to flat bottom cone roof tanks with limited roof apex angle. This video documents the research and testing on frangible joint storage tanks performed at kansas state university and thunderhead engineering. In fact the frangible roof design fulfills the venting requirements due to deflagrations inside tanks for most tank sizes greater than about 35 feet in diameter. Api 650 gives rules for the design of frangible roof joints in fluid storage tanks.

This failure is intended to vent the tank and contain any remaining fluid.
